FSF Series Filter System
( For residential pools )
FSF Series Filtration Combo includes:
1. Top mount fiberglass filter tank
2. 6-Way Multiport Valve
3. SS or SC Series Pump
Product Features
Valve
6-Way Multiport ValveMax Working Pressure
36psi (2.5bar)Max Water Temperature
43°C (109°F)Suggested Size of Media
0.5mm - 0.8mm
Technical Information
| Code | Model | Filter | Pump | Filter & Pump Connection | Max. Flow Rate | Sand ( Kg ) |
|---|---|---|---|---|---|---|
| 88032009 | FSF350-6W | V350 | SS033 | 1.5" 50 mm | 72 lpm 4.32 ㎥/h | 20 |
| 88032110 | FSF400-6W | V400 | SS050 | 1.5" 50 mm | 108 lpm 6.48 ㎥/h | 35 |
| 88032111 | FSF450-6W | V450 | SS075 | 1.5" 50 mm | 135 lpm 8.1 ㎥/h | 45 |
| 88032324 | FSF500-6W | V500 | SC100 | 1.5" 50 mm | 185 lpm 11.1 ㎥/h | 85 |
| 88032425 | FSF650-6W | V650 | SC150 | 1.5" 50 mm | 260 lpm 15.6 ㎥/h | 145 |
