Volumetric Filters

( Top Mount )

One-piece blow-molded filter tank combining the technology of structural engineered high-density polyethylene material manufactured to maximize the strength of the filter. It is perfectly suited for all pools with different disinfection systems (Salt chlorinator , Ozone, UV, and chemical dosing). The Volumetric Filter is designed for the best clarity of filtered water and has an outstanding pressure standard among the market benchmarks.

The filter incorporates a multiport valve manufactured from robust components to create the most efficient, reliable, and user-friendly filter positioning it in the market for the best return on investment.

Product Features

Tank Material
HDPE
Max Operating Pressure
58psi (4.0bar)
Max Temperature
50°C (122°F)
Suggested Size of Media
0.5mm - 0.8mm

Product Highlights

1. 6-way Multiport Valve

Unique design allows tool-free service and maintenance.

2. Handy Clamp Lock

The hinged clamp allows 360° rotation of the valve to simplify installation and plumbing work.

3. Filteration Bed

30% higher filtration bed promotes deeper water filtration for better water quality.

4. Filter Tank

An innovative T-shaped filter tank is designed for better backwashing. The tank in HDPE material can withstand higher water pressure and water temperature.

5. Drain Cover

Robust and reliable to reduce operating and maintenance costs.

6. Double-layered lateral system

Benefits from uniform filtered water collection and provides thorough backwashing of the filter media.

Technical Information

Code	Model	Filter Area ( ㎡ )	Valve Connections	Max Flow Rate ( ㎥/h )	Sand ( Kg )
88016003	T450	0.16	1.5" 50mm	8	75
88016004	T500	0.2	1.5" 50mm	10	95
88016046	T600	0.29	1.5" 50mm	14.6	165
88016007	T700	0.39	1.5" 50mm	19.5	200
88016047	T600B	0.16	2" 63mm	14.6	165
88016008	T700B	0.16	2" 63mm	19.5	200
